2018 Hot Sales High Power BLDC Motor Driver With Multi Mode Type

FOB Reference Price:Get Latest Price
US $1-48.06 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Package:
Antistatic bag, Standard Package
Model Number:
RB-01C115
Type:
Education
Brand Name:
ALSRobot
Place of Origin:
Guangdong, China (Mainland)
Product Name:
Multi BLDC Mode Motor Driver
Working voltage:
6V-24V
Size:
72.747mmx47.244mm
Weight:
30g
Color:
Blue
Condition:
Original 100%
Shipping by:
DHL\UPS\Fedex\EMS\HK Post
Delivery Time:
Within 2-3 days after payment confirmed
Port:
Shenzhen
SupplyAbility
SupplyAbility:
1000 Set/Sets per Week
Packaging & Delivery
Packaging Details
Standard Box
Port
Shenzhen
Lead Time :
3-7 working days

Description

The multi-mode motor driver board is a high-power motor driver board that Aosong developed without programming.



It can drive two DC motors at the same time, each channel up to 10A. Input voltage range 6-24V, support 5-18 lithium battery power supply.



The multi-mode motor driver board has four operating modes to choose .simulate input mode, R/C input mode, simple serial port mode and packetized serial port mode. The combination of different modes of on-board dialing switches is switched in different modes to realize the creative development of robots.



The multi-mode motor driver board can accomplish the simultaneous control or independent control of the steering and rotation speed of the two DC motors without programming, and reduces the development difficulty and cost in the development of the robot movement or the wheeled mobile platform. A multi-mode motor driver board and its rich features make robotics more creative.



Features



  • Mode can be used independently or in combination
  • Synchronous regeneration drive
  • High switching frequency (above human hearing range)4.
  • Overheating and overcurrent protection
  • Various operating modes

pictures



Multimode moter driver2.jpg

Digital signal output     &  Sensor 3P Interface











Multimode moter driver4.jpg



Highly efficent & More convenience

Drive two DC motors at the same time









Multimode moter driver5.jpg

Behind  show

    perfect in workmanship    complete information

Specifications.



Pin definition:
  B-: Negative electrode
  B+: Positive Power Supply
  M1A: Motor 1 Forward Interface
  M1B: Motor 1 Reverse Interface
  M2A: Motor 2 Forward Interface
  M2B: Motor 2 Reverse Interface
  S1: Signal 1 input
  S2: Signal 2 input



Test environment :
1. Hardware environment: Arduino UNO R3, rotary angle potentiometer x2, USB to TTL serial port module, 2.4G wireless remote control handle and receiver
2. Software Environment: Arduino IDE 1.7.7
Recommended power supply
1. NiMH or NiCd battery pack
2. Li-ion lithium-ion battery pack, or lithium polymer battery (this module is designed with lithium battery protection function to prevent lithium battery from losing charge capacity due to over-discharge)
3.7.4V to 24V lead-acid battery
4.7.4V to 24V Transformer


5. Attention!

This module is not recommended to use transformer power supply. If using transformer power supply, it is recommended to use a battery pack with the same voltage in parallel with the transformer. Please confirm the transformer current output capability when power is supplied to prevent transformer and module damage
